smart magnetic led light strip dimmable & tunable

smart magnetic led light strip dimmable & tunable

led troffer retrofit kit | fluorescent to led retrofit kits | Bluetooth magnetic led light strip is a long-lasting and money-saving solution that retrofit traditional fluorescent 1x4, 2x2, 2x4 light fixtures.

smart magnetic led light strip dimmable & tunablesmart magnetic led light strip dimmable & tunablesmart magnetic led light strip dimmable & tunablesmart magnetic led light strip dimmable & tunablesmart magnetic led light strip dimmable & tunable
Inquire Now

Magnetic led light strip led troffer retrofit kit


ARK lighting fluorescent to led retrofit kits is a long-lasting and money-saving solution that retrofit traditional 1x4, 2x2, 2x4 light fixtures. Kits offer high-efficiency 140-150lm/w, Eco-Friendly, and simple magnetic installation.


Applications including offices, lobbies, hallways and conference rooms in schools municipalities, libraries, airport, healthcare facilities and so on.


 smart magnetic led light strip dimmable

Magnetic led light strip features:


1. Input at AC100-277V.

2. 3000K,3500K,4000K,4500K,5000K CCT.

3. 150lm/w without cover or 140lm/w with cover.

4. The external driver from 9w to 72w.

5. Dimming optional.

6. Magnet adhesive, and installation hole on both ends.




Structures of led troffer retrofit kit

magnetic led light strip fluorescent to led retrofit kits structure



Specification of Magnetic led light strip led troffer retrofit kit



1 strip for troffer2 strips for troffer3 strips for troffer4strips for troffer
Power8W
16W24W32W
ModelARK/DT/16K**D106(13D)ARK/DT/16K**D206(13D)ARK/DT/24K**D306(13D)ARK/DT/32K**D406(13D)
Luminous Flux140LM140LM140LM140LM
Power
12W24W36W48W
ModelARK/DT/12K**D112(13D)ARK/DT/24K**D212(13D)ARK/DT/36K**D312(13D)ARK/DT/48K**D412(13D)
Luminous Flux140LM140LM140LM140LM
Power18W36W54W72W
ModelARK/DT/18K**D112(13D)ARK/DT/36K**D212(13D)ARK/DT/54K**D312(13D)ARK/DT/72K**D412(13D)
Luminous Flux140LM140LM140LM140LM
DLC certificationY
YYY
Dimension2ft: 22"4ft: 46"
Light SourceSMD2835 LED
Luminous Efficacy>140lm/w
Operation Temp-40 to +45℃
CCT2700K -- 6700K CW
CRI80
Life Span50,000 hours at 25℃
Voltage100-277VAC / 50-60HZ
DriverUL listed power supply
Emergency ModuleAvailable
Dimming0-10V
SensorDaylight sensor Microwave motion available 2 & 1
Beam Angle120°
PF>0.95
Warranty5 Years


Wireless Bluetooth Remote Control Switch


led troffer retrofit kit Bluetooth APP Switch

· Wireless Bluetooth mesh connection.

· No gate, password, internet, or cloud connection needed.

· Area/Group control, group linkage.

· Visualized map, by using blueprint or photo to install or control light.

· Real-time energy-saving calculation.

· Auto emergency battery test.




Bluetooth mesh wireless app & remote control



Bluetooth APP ControlBluetooth 2x4 led troffer 2x2 dimmable

Support iOS, Android phones.

Easily add and manage lamps and smart switches.

* Use APP to group lamps.

* Set lighting scenes.

* Manage timer tasks.

* Configure delay time of human motion sensor.

* Configure group linkage control.

* Manage lamps of different areas in one smartphone.

* Share control privilege among smartphones

* Assign different privileges to staff to manage lamps.

* Compatible with most Android phones



led troffer retrofit kit Bluetooth Panel Switch

Powered by two AAA batteries.

Bluetooth communication.

No wires needed. Easy installation: suitable for surface-mounted or recessed in the wall. Or just leave it on the desk.

When the voltage less than 2.6V, press any buttons and the red light flashes.

dimmable t8 led panel switch


Industries We Serve

The intelligent energy-efficient lighting control system


dimmable t8 led tube light application

dimmable t8 led tube light project



smart magnetic led light strip dimmable & tunable
smart magnetic led light strip dimmable & tunable

Installation instructions:

-->

magnetic led light strip fluorescent to led retrofit kits

Package infomation of Magnetic led light strip fluorescent to led retrofit kits



2'x2'2'x4'Driver

L(cm)*W(cm)*H(cm)L(cm)*W(cm)*H(cm)L(cm)*W(cm)*H(cm)
Carton size65*30*27.5125*30*27.535.2*30.5*10.8
Q’ty/CTN10010030
N.W(KG)4.58.67.5
G.W(KG)5.59.58.5

0.6M

Package size(mm)
20'GP : 5898×2352×2385
A: 1380*880*1050
  B: 1380*1150*1050
1x1 tube:21000 PCS
1x2 tube:25200 PCS
1x3 tube:25200 PCS
1x4 tube:12600 PCS
20'GP : 1260*1100*1100
40'GP :12032×2352×2385
  A: 1380*880*1050
    B: 1380*1150*1050
1x1 tube:42000 PCS
1x2 tube:46200 PCS
1x3 tube:46200 PCS
1x4 tube:50400 PCS
40'GP :1260*1100*1100
40'HQ :12032*2352*2690
A: 1380*880*1050
B: 1380*880*1350
1x1 tube:42000 PCS
1x2 tube:46200 PCS
1x3 tube:46200 PCS
1x4 tube:58800 PCS
40'HQ :1450*960*1230
1.2M
Package size(mm)
20'GP : 5898×2352×2385
  A: 1300*1150*1050
B: 1300*870*1050
1x1 tube:12600 PCS
1x2 tube:14400 PCS
1x3 tube:14400 PCS
1x4 tube:14400 PCS
20'GP : 960*1100*1000
40'GP :12032×2352×2385
  A: 1300*1150*1050
B: 1300*870*1050
1x1 tube:29400 PCS
1x2 tube:31200 PCS
1x3 tube:33600 PCS
1x4 tube:33600 PCS
40'GP :A:1260*1100*1100
40'HQ :12032×2352×2690
  A: 1300*1150*1050
B: 1300*870*1050
1x1 tube:29400 PCS
1x2 tube:31200 PCS
1x3 tube:33600 PCS
1x4 tube:31800 PCS
40'HQ :1260*1100*1230



how motion & daylight sensor works?
